Specification
  Transmitter  Receiver (Sold Separately)
Video Input SDI/HDMI
Video Output   SDI/HDMI
SDI Input Format 1080p 23.98/24/25/29.97/30/50/59.94/60fps
Level A/B

SDI Output Format   1080p 24/25/30/50/60fps
Level A
HDMI Input Format 1080p 23.98/24/25/29.97/30/50/59.94/60fps
HDMI Output Format 1080p 23.98/24/25/29.97/30/50/59.94/60fps 1080p 24/25/30/50/60fps
DC Port 5.5mmx2.1mm, center positive
DC Voltage 7.4~16.8V
Audio 44.1KHz/48KHz 16bit/24bit PCM
Latency <0.05s
(Camera latency not included)

OLED Display 1.3 inch 1.3 inch
Transmission Power 17~20dBm
Transmission Range 1200ft
(No obstacles, no interference)

Power Consumption 4.5 Watt
(Typical)
3.5 Watt
(Typical)
Operating
Environment Temperature
-10~40℃
Dimensions
(Antennas Not Included)
105mmx66mmx32mm
Weight
(Antennas Not Included)
210g 210g
SKU WIT04-SETX
Barcode # 664918771782
Brand Accsoon
Shipping Weight 1.0000kg
Shipping Width 0.250m
Shipping Height 0.150m
Shipping Length 0.200m
